Mobile Crane Truck

Products are defined for different uses and niche markets, with a complete and diverse range. The combination of Weichai engine and Fast transmission makes the power more robust and energy saving more efficient. Compatible layout, suitable for various crane modifications.

Technical Parameters

Engine Model WP2.5NQ170E62 WP2.5NQ170E62 WP3NQ160E61 WP3NQ160E61 WP4.1NQ160E61 WP4.6NQ220E61A WP4.6NQ220E61A
Net Power (KW) / Speed (r/min) 125/2900 125/2900 118/3000 118/3000 118/3000 162/2300 162/2300
Maximum Torque (Nm) / Speed (r/min) 450/1400-2200 500/1400-2200 480/1400-2300 480/1400-2300 480/1400-2300 850/1200-1800 850/1200-1800
Transmission 8J50TA 8JS85TE 8JS65E 8JS65E 8JS65E 8JS85E 8JS85E
Clutch (mm) Φ325 Φ325 Φ350 Φ350 Φ395 Φ395 Φ395
Rear Axle Model 1061J（5T） 1080（7.2T） 1080（7.2T） 1080（7.2T） 153AS（9T） 153S（10T） 153S（10T）
Rear Axle Ratio 4.875 4.875 4.875 5.571 4.875 4.875
Fuel Tank (L) 120 120 120 150 200 200
Frame Cross-section (mm) 180 216 216 216 250 280 280
Suspension (Front and Rear Springs) 11/9+7 11/9+7 11/9+7 9/11+8 9/11+8 9/11+8
Tires 7.00R16,8.25R16 7.00R16,8.25R16 8.25R16 8.25R20,9.00R20 8.25R20,9.00R20 10.00R20

Vehicle Configuration

Overall Vehicle Parameters
Engine Model WP2.5NQ170E62 WP2.5NQ170E62 WP3NQ160E61 WP3NQ160E61 WP4.1NQ190E61 WP4.6NQ220E61A
Dimensions (mm) 5900x1980x2180 5900x1980x2180 6075x2180x2390 6915,7260,7565x2180x2390 6915,7260,7565x2180x2390 8930x2180x2390
Wheelbase (mm) 3280 3650 3650 3900 3900,4200,4500 5200
Front/Rear Overhang (mm) 1175/1445 1175/1075 1175/1075 1240/1775 1240/1775, 1240/1825 1280/2450
Maximum Total Mass (Kg) 11200 11200 11200 11200,14060 14060,16000 18000
Seated Passenger Capacity 2,3 2,3 2,3 2,3 2,3 2,3
#
